Full-auto Rubber & Plastic Injection Machine
Product Description
The automatic mold sliding and mold tilting structure reduces labor intensity and increases production efficiency.
The automatic servo control system saves energy and reduces consumption by 30%.
The hydraulic system adopts a logic circuit, providing stable pressure and fast mold opening/closing speeds.
The wall-plate type frame structure offers high rigidity and resistance to deformation.
Automatic center platen lifting ensures safety and stability.
Product Applications
Single-color and two-color rubber shoe soles, conductive rubber, automotive parts, and various other rubber product molding.
Technical Specifications
| Model | Number of Stations | Heating Method | Clamping Force (ton) | Power (HP) | Mold Space (mm) | Number of Layers | Machine Dimensions (m) | Pitch (mm) |
|---|---|---|---|---|---|---|---|---|
| YJ-7206CS | 6 | Electric, Steam, Oil | 180 | 20 | 450×500 | 2 | 7.66×2.28×— | 205 |
Note: The machine dimensions in the original document are missing the height value. Please verify against the original specification sheet.
